Resolution

0.1A

Accuracy

±2%rdg±3dgt

CT Size

30mmX35mm

Meter Dimension

175mmX70mmX38mm

Weight

200g

Communication Interface

USB, storage data can be uploaded to computer save and print

Power Supply

DC9V Alkaline battery 6LR61 9V

Working Current

10mA

LCD Size

35mmX21.5mm; display area: 32mmX15mm

Sampling Rate

2 times/second

Communication Parameters

Baud rate: 9600, data bit: 8, stop bit: 1, check bit: NONE

Data Storage

99 groups, flash display “FULL” symbol indicate storage full

Data Hold

Data hold function: “DH” symbol display

Overflow Display

Exceed measure range overflow function: “OL A” symbol display

Polarity Indication

In DC current test auto identified and display“—” symbol

Auto Shut Down

5 Minutes after power on, it will shut down automatically without any operation to reduce the power consumption.

Battery Voltage

Battery voltage lower than 7.2V will display low battery voltage symbol, and remind to replace battery

Line Voltage

Below 600V circuit measurement

Accessories

Meter: 1PCS; USB special communication cable: 1PCS; 6LR61 battery: 1PCS; Tool bag: 1PCS
